PRODUCT
AVBR80120H48
Start Freq. (MHz) : 8000
Stop Freq. (MHz) : 12000
Pout (W) : 60
Gain(dB) : 48
Vd (VDC) : 28
Current(A) : 7.5
Description
The AVBR80120H48 is a 60W high gain Solid State Broadband High Power Amplifier. This amplifier module utilizes the latest high power RF GaN transistors and also features built in control and monitoring, with protection functions to ensure high availability. This amplifier is suitable for broadband jamming and EMC testing.
Features
Description
|
Description |
Symbol |
Min |
Typ |
Max |
Unit |
|
Operating Frequency |
BW |
8 |
|
12 |
GHz |
|
Output Power CW @Pin=10dBm |
PSAT |
50 |
45 |
|
W |
|
Power Gain @Pin= 10dBm |
Gp |
|
56 |
|
dB |
|
Power Gain Flatness @Pin= 10dBm |
∆Gp |
|
±1.0 |
±1.5 |
dB |
|
Input Power for Rated Psat |
PIN |
-3 |
-0 |
-3 |
dBm |
|
Harmonics @ Pin=-0dBm |
2nd |
|
-40 |
-30 |
dBc |
|
Noise Figure |
NF |
|
N/A |
|
dB |
|
Spurious Signals @Pin= 0dBm |
Spur |
|
-70 |
-65 |
dBc |
|
Input Return Loss |
S11 |
|
|
-10 |
dB |
|
Operating Voltage |
VDC |
26 |
28 |
30 |
V |
|
Current Consumption @ Pout= 50~60W |
IDD |
|
7.5 |
8.5 |
A |
|
Switching Time @ 1kHz TTL* |
TON/TOFF |
|
1 |
2 |
µs |
