0.8-3.0GHz SSPA Series: High Performance & Versatility

2025-02-20


AmpliVisionS offers a range of high-power solid-state broadband amplifiers

0.8-3.0GHz SSPA Series: High Performance & Versatility

AmpliVisionS offers a range of high-power solid-state broadband amplifiers designed to meet the demands of modern EMC testing and broadband jamming applications. Our 0.8-3.0 GHz series includes the latest RF technology, ensuring superior performance, reliability, and efficiency.

AVBR0810H47
· Frequency Range: 800-1000 MHz
· Power Gain: 48dB
· Psat: 47dBm (Min)
· Solid-State Class AB Broadband Design
· Built-in Control, Monitoring & Protection Circuits
· Small, Lightweight & Rugged
This solid-state amplifier module features the latest high-power RF LDMOS transistors, offering high reliability and advanced protection functions to ensure high availability. Ideal for applications like broadband jamming and EMC testing.

AVBR0820H52
· Frequency Range: 0.8-2 GHz
· Power Gain: 52dB
· Psat: 52.3dBm (Typ.), 51.8dBm (Min.)
· High Average Efficiency (around 42%)
· Suitable for CW & Pulse Signals
· Output Power Level Indicator
· Small, Lightweight & Rugged
The AVBR0820H52 amplifier is perfect for high-power combinations, offering superior efficiency, outstanding linearity, and advanced protection features, making it an excellent choice for broadband jamming and EMC testing.

AVBR0830H47
· Frequency Range: 0.8-3 GHz
· Power Gain: 48dB
· Psat: 47dBm (Min)
· Solid-State Class AB Broadband Design
· Suitable for CW, Pulse, and Modulated Signals
· Built-in Control, Monitoring & Protection Circuits
· High Efficiency, Reliability, and Ruggedness
Offering solid-state Class AB broadband design, this amplifier is optimized for linear systems, with excellent amplitude and phase consistency. It’s perfect for demanding high-power combinations and a wide range of testing applications.

■
